Installation Guide

2 Installation Procedure

2.1 Mounting the Camera Base
Note: The camera base mounting procedure describes how to mount the
camera directly to a solid surface such as a wall or a hard ceiling. Optional kits
are available that allow the camera to be mounted in other fashions (such as
in a suspended ceiling). If you are using one of these kits, refer to the
instructions included with the kit to determine how to mount the camera.
1. Remove the dome from the camera base.
(For shipping, the dome will be held to the camera base with tape.
Remove the tape to separate the dome from the camera base.)
6
Dome
Camera
Base
