If you will not be using the camera's audio connections, go on to Section 3 on
page 20 now.
If you will be using the camera's audio connections, read the note below and
then continue on with step 5.
Note: The following steps describe using the Y-cable assembly that is included
with the camera to make audio connections. If you want to run wiring directly
to the audio connector without using the Y-cable, see the camera user's
manual for details about the audio connector type and pin assignments.
5. Get the Y-cable assembly that is included with the camera.
6. Plug the four-pin connector on the end of the cable into the audio
connector on the camera base as shown below.
