AW00101404000
2.2 Installing Camera Cables Through the Side
Pass-Through Hole
Notes: This procedure describes how to install the cables using the weather-
proof connection included with the outdoor dome camera kit.
The procedure describes an installation that uses two cables, an Ethernet
cable and a secondary cable. If you are only using a single PoE cable,
installation is similar, but uses a grommet with only one groove.
1. Screw the nipple into the side of the camera base. Be sure to tighten the
nipple enough so that the O-ring is squeezed between the nipple and the
camera base. This is required to make a weather-proof seal.
O-ring
Nipple
Basler IP Fixed Dome Cameras
Installation Guide
11
