Now it is important that the
reference electrodes are inserted
correctly. They must be inserted in
the reservoirs where the Haber-
Luggin capillaries face the
membrane. One reference electrode
must be inserted in the reservoir
with the sticker RE2 in analyte
compartment 1 as the Haber-Luggin
capillary is aligned there towards
the membrane.
The second reference electrode
must be inserted in the reservoir
with the sticker RE1 in analyte
compartment 2.
Galvanic coatings
Electroplating of your samples can also be carried out with the ElyFlow system, as you
can assemble the system to suit your task by combining the individual modules.
Measuring hydrogen permeation
The ElyFlow-system is excellent for measuring hydrogen permeation.
Together with IChemAnalytics
system, consisting of the ElyFlow test cell from Gaskatel and the Automated
Measurement and Control Box (AMB) from
When examining steel foils, it is also possible without Pd coating on the oxidation side
of the sample.
With this system, you can perform a wide range of electrochemical measurement and
control tasks:
In situ monitoring of hydrogen evolution during electrochemical coating, including
•
monitoring of the potential at the phase boundary.
In situ monitoring of hydrogen evolution in pre-treatment processes, such as
•
pickling processes, in conjunction with monitoring of the electrochemical potential
at the phase boundary.
Monitoring of production process parameters with regards to hydrogen
•
embrittlement.
Determination of H-diffusion coefficients in metallic materials in dependence of
•
the morphological material properties.
Further information you will find at
GmbH, Gaskatel offers a complete measurement
IChemAnalytics
www.gaskatel.com.
