Rotary SM65 Originalanleitung Seite 73

78 B24-5*12
79 CH4-2003
80 SM60-1406
81 SM60-1415
82 SM65-1428
83 SM65-1409
84 H4P-3003A
85 B60-10
86 SM60-9300
87 SM65-1418
88 B30-6
89 B72-6
90 SM60-1417
91 SM65-1416
92 FC522-25Y
93 SM65-1407
94 SM65-1408
95 52005-3A
96 SM60-1411
97 H4P-1014
98 B30-10
99 SM60-1410
100 B85-6
101 B23-6*12
102 B41-6
103 H4P-1007B
104 SM65-1101
105 SM65-1104
106 SM65-1103
107 SM65-1101-1
108 SM65-1102
109 SM65-1101-2
110 SM60-1102
111 H4P-3001
112 SM65-1123-3
113 SM65-1123-4
114 SM65-1123-1
115 SM65-1123-2
116 SM65-1124
117 B11-10*40
118 B23-4*10
Crosshead Recessed Screw M5*12
Protect Plate
Bar
Lock shaft
Spacer
Shaft,cable sheave
Cable sheave
Snap ring φ10
Air Cylinder
Air Cylinder Pin
Nut M6
M6 Sealmaster
Safety latch,slack cable
Safety latch
Spring
Spacer
Spacer
Bearing
Shaft
Roll sleeve
Nut M10
Top cover ,Crossbeam Ends
Oil Cup M6
Cross Recess Head Screw M6*12
Flat washer φ6
Sleeve
Spacer（8mm)
Spacer（56mm)
Spacer（46mm)
Spacer（22mm)
Spacer（65mm)
Spacer（94mm)
Spacer（37mm)
Washer
Shaft,cable sheave 3
Shaft,cable sheave 4
Shaft,cable sheave 1
Shaft,cable sheave 2
Support plate
hexagon-headed bolt M10*40（8.8grade）
Cross Recess Head Screw M4*10
16
8
1
4
4
4
11
8
4
4
4
4
4
4
8
4
4
8
4
4
4
4
8
8
8
11
2
1
1
1
1
1
1
15
1
1
1
1
1
4
2
