Endress+Hauser iTHERM ModuLine TM131 Technische Information Seite 45

iTHERM ModuLine TM131
Endress+Hauser
PN25
DN D b
25 115 (4,53) 18 (0,71)
32 140 (5,51) 18 (0,71)
40 150 (5,91) 18 (0,71)
50 165 (6,5) 20 (0,79)
65 185 (7,28) 22 (0,87)
80 200 (7,87) 24 (0,94)
100 235 (9,25) 24 (0,94)
125 270 (10,6) 26 (1,02)
150 300 (11,8) 28 (1,10)
200 360 (14,2) 30 (1,18)
250 425 (16,7) 32 (1,26)
300 485 (19,1) 34 (1,34)
PN40
DN D b
15 95 (3,74) 16 (0,55)
25 115 (4,53) 18 (0,71)
32 140 (5,51) 18 (0,71)
40 150 (5,91) 18 (0,71)
50 165 (6,5) 20 (0,79)
65 185 (7,28) 22 (0,87)
80 200 (7,87) 24 (0,94)
100 235 (9,25) 24 (0,94)
125 270 (10,6) 26 (1,02)
150 300 (11,8) 28 (1,10)
200 375 (14,8) 36 (1,42)
250 450 (17,7) 38 (1,50)
300 515 (20,3) 42 (1,65)
PN63
DN D b
25 140 (5,51) 24 (0,94)
32 155 (6,10) 24 (0,94)
40 170 (6,69) 26 (1,02)
50 180 (7,09) 26 (1,02)
65 205 (8,07) 26 (1,02)
80 215 (8,46) 28 (1,10)
100 250 (9,84) 30 (1,18)
125 295 (11,6) 34 (1,34)
150 345 (13,6) 36 (1,42)
200 415 (16,3) 42 (1,65)
K d
85 (3,35) 68 (2,68)
100 (3,94) 78 (3,07)
110 (4,33) 88 (3,46)
125 (4,92) 102 (4,02)
145 (5,71) 122 (4,80)
160 (6,30) 138 (5,43)
190 (7,48) 162 (6,38)
220 (8,66) 188 (7,40)
250 (9,84) 218 (8,58)
310 (12,2) 278 (10,9)
370 (14,6) 335 (13,2)
430 (16,9) 395 (15,6)
K d
65 (2,56) 45 (1,77)
85 (3,35) 68 (2,68)
100 (3,94) 78 (3,07)
110 (4,33) 88 (3,46)
125 (4,92) 102 (4,02)
145 (5,71) 122 (4,80)
160 (6,30) 138 (5,43)
190 (7,48) 162 (6,38)
220 (8,66) 188 (7,40)
250 (9,84) 218 (8,58)
320 (12,6) 285 (11,2)
385 (15,2) 345 (13,6)
450 (17,7) 410 (16,1)
K d
100 (3,94) 68 (2,68)
110 (4,33) 78 (3,07)
125 (4,92) 88 (3,46)
135 (5,31) 102 (4,02)
160 (6,30) 122 (4,80)
170 (6,69) 138 (5,43)
200 (7,87) 162 (6,38)
240 (9,45) 188 (7,40)
280 (11,0) 218 (8,58)
345 (13,6) 285 (11,2)
L ca. kg (lbs)
4x⌀14 (0,55) 1,50 (3,31)
4x⌀18 (0,71) 2,00 (4,41)
4x⌀18 (0,71) 2,50 (5,51)
4x⌀18 (0,71) 3,00 (6,62)
8x⌀18 (0,71) 4,50 (9,92)
8x⌀18 (0,71) 5,50 (12,13)
8x⌀22 (0,87) 7,50 (16,54)
8x⌀26 (1,02) 11,0 (24,26)
8x⌀26 (1,02) 14,5 (31,97)
12x⌀26 (1,02) 22,5 (49,61)
12x⌀30 (1,18) 33,5 (73,9)
16x⌀30 (1,18) 46,5 (102,5)
L ca. kg (lbs)
4x⌀14 (0,55) 0,81 (1,8)
4x⌀14 (0,55) 1,50 (3,31)
4x⌀18 (0,71) 2,00 (4,41)
4x⌀18 (0,71) 2,50 (5,51)
4x⌀18 (0,71) 3,00 (6,62)
8x⌀18 (0,71) 4,50 (9,92)
8x⌀18 (0,71) 5,50 (12,13)
8x⌀22 (0,87) 7,50 (16,54)
8x⌀26 (1,02) 11,0 (24,26)
8x⌀26 (1,02) 14,5 (31,97)
12x⌀30 (1,18) 29,0 (63,95)
12x⌀33 (1,30) 44,5 (98,12)
16x⌀33 (1,30) 64,0 (141,1)
L ca. kg (lbs)
4x⌀18 (0,71) 2,50 (5,51)
4x⌀22 (0,87) 3,50 (7,72)
4x⌀22 (0,87) 4,50 (9,92)
4x⌀22 (0,87) 5,00 (11,03)
8x⌀22 (0,87) 6,00 (13,23)
8x⌀22 (0,87) 7,50 (16,54)
8x⌀26 (1,02) 10,5 (23,15)
8x⌀30 (1,18) 16,5 (36,38)
8x⌀33 (1,30) 24,5 (54,02)
12x⌀36 (1,42) 40,5 (89,3)
45
