Dismounting and disposal
Charge specialized personnel with the disposal that is familiar with the possible risks and with the present manual.
When the machine is not used any more and is to be disposed of, proceed as follows:
• Cut off the electric power supply.
• Empty the oil tank, fill the oil in a tight bin and bring it to a specialized public collection facility following your
country's regulations.
• Take all other machine parts to a scrap collection facility following your country's regulations.
Be sure every machine part is disposed of following your country's regulations.
In case of any malfunctions not mentioned here, contact your dealer's after-sales service.
Malfunction
The hydraulic pump does
not start
The column does not
move down
Motor starts but column
does not move down
Maintenance and repairs
All servicing jobs must be executed by specialized personnel under strict observation of the present operating in-
structions. Before every work, every possible caution must be taken: Switch off the motor, disconnect the
power supply (pull the plug, if necessary). Attach a board to the machine explaining the reason for being out
of order: "Machine out of order due to servicing work: Unauthorized people must not come close to the machine
or switch it on."
Trouble shooting
Possible cause
No electric power
Thermal switch of motor
cut off
Low oil level
One of the levers not
connected
Dirt in the rails
Wrong turning direction of
3-phase motor
Remedy
Check cable for electric
power
Wait till motor is cooled
down and start motor
again.
Check oil level and refill
Check fixing of lever
Clean the column
Check turning direction of
motor and change
Danger class
Risk of electric shock.
This job must be done by
a service electrician.
Risk of getting dirty.
This job can be done by
the machine operator.
Risk of getting cut.
This job can be done by
the machine operator.
