Attach the Slammer™ Competition 180 Goal
G
ATTACH THE SLAMMER™ COMPETITION 180 GOAL
2. Slide the rim (3) down onto the bolts (24) behind the washers (26).
3. Install the top two bolts (24), washers (26), lockwashers (28), and nuts (41).
4. Tighten all hardware completely.
#7
#3
#7
#28
#41
#3
#24
#26
5. Remove pre-installed Easy Glide™ cable from the rim (3).
6. Reinstall while inserting all net loops into slots along ring.
7. Position the spring lock between the ring slots.
8. The cable protruding from the spring lock inserts into the tube and the metal end rests against
the tube.
#3
