Attach the Backboard
E
ATTACH THE BACKBOARD
3. Pivot the backboard up to align with the upper yoke arm (11).
4. Attach the backboard to the upper yoke arm (11) using the hinge pin (36), washers (37),
lockwashers (32) and bolts (35).
#11
#10
#35
#32
#37
#36
#37
#32
#35
5. Grease the installed hinge pins (36) for the board connection using the supplied grease gun.
