Raise and Lock the Pole
H
RAISE THE POLE
4. Remove the hitch pin (18) and cotter pin (19).
5. Remove the nut (17), washer (22), and barrel washer (21) and the rod (20).
6. Remove the nut (16) and bolt (15). Raising the front of the nuts (27) from below the pole will be
needed for this step and for the next steps.
#1
#15
#27
#2
#1
#27
#2
28
#17
#22
#21
#20
#18
#19
