Batteries heat up when charging. Do not operate just after charging –
wait for the battery to cool down to room temperature. It will prevent
battery damage.
BATTERY LEVEL INDICATION
The battery is equipped with indication of the battery level (3 LED
diodes) (16). To check battery level status, press the button for battery
level indication (15) (fig. C). When all diodes are lit, the battery level is
high. When 2 diodes are on, the battery is partially discharged. When
only one diode is lit, the battery is discharged and must be recharged.
The power tool is equipped with electronic brake, which stops the spindle
immediately after the switch button (10) is released. The brake allows for
precise driving and prevents free spindle rotation after switching off.

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF
Switching on – press the switch button (10).
Switching off – release the switch (10).
Each time the switch button (10) is pressed, the LED diode (7) turns on
to illuminate the workplace.
CHANGE OF GEAR
The impact driver features rotational speed adjustment, ranged at three
forward gears (clockwise) and two backward gears (counter-clockwise).
They can be changed with the gear switch button (8) located in the
bottom base of the impact driver.
When switching clockwise gears, one of three diodes (9) shows the
current operating gear. When you press the gear switch button (8 the
device will switch to higher or lower gear (fig. D).
When changing the direction selector switch (4) to counter-clockwise
rotation, two modes are available. With the first, the leftmost diode
turns on and the impact driver starts with full speed and slows down
shortly after (for initial impact and undoing a bolt).
Pressing the gear selector switch (8) again turns off all diodes, speed is
maximal and constant, and still adjustable with the switch (10) within
the range of the selected gear.
CIRCUMFERENTIAL IMPACT ACTION
The tool rotates the spindle when tightening, and creates circumferential
impact. Impact action actuates automatically when the load increases.
Then a high peak torque is applied. Keep watching the screw or bolt
for full control over tightening. Keep control over tightening force by
adjusting rotational speed.
WORKING TOOL INSTALLATION
In order to change socket or bit, pull forward the sleeve that keeps the
tool holder (2).
• Pull away the fixing sleeve of the tool holder (2) (fig. E) against the
spring force.
• Insert working tool shank into the tool holder (1) and slide it in to
mechanical stop (it may be necessary to turn the working tool so it
can reach appropriate position) (fig. F).
• Release the fixing sleeve of the tool holder (2), it will finally lock the
working tool. The tool holder fixing sleeve (2) will return to its home
position.
Deinstallation of the tool is similar to installation, only the sequence of
actions is reversed.
It is recommended to use driver bits designed for holders with
automated fixing system. Use additional driver bit adapter with
short driver bits.
RIGHT-LEFT DIRECTION OF ROTATION
Choose direction of spindle rotation with the direction selector switch
(4) (fig. G).
Clockwise rotation – move the switch (4) to the far left position.
Counter-clockwise rotation – move the switch (4) to the far right
position.
* In certain cases position of the switch related to rotation may be different than specified. Please refer to
graphic signs located on the switch or tool body.
Safe position of the direction selector switch (4) is in the middle, it
prevents accidental starting of the power tool.
• When the switch is in this position, the power tool cannot be started.
• Use this position of the switch to change bits.
• Make sure that the position of the direction selector switch (4) is
correct before starting the tool.
Do not change direction of rotation when the spindle of the power
tool is rotating.
Long lasting operation at low rotational speed of the spindle may cause
motor overheating. Make periodic breaks in operation or allow the tool
to operate at top speed without load for approximately 3 minutes.
HOLDER
The power tool provides convenient holder (6) that allows to e.g. hang
the tool on a tool belt when working at heights.

OPERATION AND MAINTENANCE

MAINTENANCE AND STORAGE
• Cleaning the device after each use is recommended.
• Do not use water or any other liquid for cleaning.
• Clean the power tool, battery and charger with a dry cloth or blow
through with compressed air at low pressure.
• Do not use any cleaning agents or solvents, they may damage plastic
parts.
• Clean ventilation holes in the motor casing regularly to prevent
device overheating.
• In case of excessive commutator sparking, have the technical
condition of carbon brushes of the motor checked by a qualified
person.
• Store the power tool and its equipment in a dry place, beyond reach
of children.
• Store the device with the battery removed.
All defects should be repaired by service workshop authorized by the
manufacturer.

TECHNICAL PARAMETERS

RATED PARAMETERS
Cordless impact driver 58G024
Parameter
Battery voltage
Max. torque (gear I / II / III)
Range of spindle rotational speed
without load (gear I / II / III)
Range of impact rate (gear I / II / III) 0-1400 / 0-2520 / 0-3780 min
Tool holder
Protection class
Weight
Year of production
58G024 defines type and indication of the device
Graphite Energy+ System Battery
Parameter
Battery
Battery voltage
Battery type
Battery capacity
Ambient temperature range
Charging time for charger 58G002
Weight
Year of production
Graphite Energy+ System Charger
Parameter
Charger type
Supply voltage
Power supply frequency
Charging voltage
Max. charging current
Ambient temperature range
Charging time of the battery 58G001
Charging time of the battery 58G004
Protection class
Weight
Year of production
10
Value
18 V DC
80 / 120 / 200 Nm
0-1000 / 0-1800 / 0-2700 rpm
-1
Hexagonal 6.35 mm (¼")
III
1.1 kg
2021
Value
58G001
58G004
18 V DC
18 V DC
Li-Ion
Li-Ion
2000 mAh
4000 mAh
4
C – 40
C
4
C – 40
C
0
0
0
0
1 h
2 h
0,400 kg
0,650 kg
2021
2021
Value
58G002
230 V AC
50 Hz
22 V DC
2300 mA
4
C – 40
C
0
0
1 h
2 h
II
0,300 kg
2021
