3 2
P O S I T I O N K B N
1 YCOQ00001
3 YCOQ00003
4 YCOQ00004
5 YCOQ00005
6 YCOQ00006
8 YCOQ00008
4 8 YCOQ00048
5 0 YCOQ00050
5 1 YCOQ00051
5 2 YCOQ00052
5 3 YCOQ00053
5 4 YCOQ00054
6 8 YCOQ00068
1 9 7 YCOQ000197
5 9 YCOQ00059
* /
/ C2WSPG
9 M A I N T E N A N C E
9 . 1 S P A R E P A R T S
NOTE
Complaints will only be processed with information on the serial number!
The serial number is placed on the return pipe of the pump group.
D E S C R I P T I O N
Ball valve DN 25, 2x plug, with device for thermometer
Gasket for G1½", EPDM, Ø 44.0 x Ø 32.0 x 2.0
Ball valve handle for thermometer, Ø 50 mm
Dial thermometer, red, 0-120 °C, Ø 50 mm
Dial thermometer, blue, 0-120 °C, Ø 50 mm
Ball valve with butterfly handle DN 25, 1" F x 1½" ext. thread
Spare parts set for ball valve DN 25
Insulation of the pump group with installation kit for heat flow meter DN 25, complete set
2 x reducer ½" ext. thread self-sealing, 1 x M12x1.5 ext. thread, 1 x M10x1 int. thread self-sealing
T-piece, l = 93 mm, 1" ext. thread x 1" int. thread x ½" int. thread
Ball valve with butterfly handle + check valve, DN 25, 1" F x 1½" ext. thread
Fitting for heat flow meter in pump groups DN 25
COSMO 2.0 union nut G1½"
Reducer ¼" ext. thread, self-sealing x M12x1.5 ext. thread or ¼" ext. thread, self-sealing x M10x1 int. thread
Pump insert for insulation, necessary when replacing COSMO CPH by CPH 2.0
Pump DN 25, 1½" ext. thread x 180 mm
Right-angle plug with 2 m cable, suitable for Grundfos / Wilo pumps and COSMO CPH 2.0
