U N M I X E D P U M P G R O U P D N 2 5 W I T H I N S T A L L A T I O N K I T F O R H E A T F L O W M E T E R
5 T E C H N I C A L D A T A
D I M E N S I O N S
Centre distance
Width insulation
Height insulation
Installation length
C O N N E C T I O N S
Outlet
Inlet
H E A T F L O W M E T E R
Connecting dimensions
T E C H N I C A L D A T A
Opening pressure check valve
H Y D R A U L I C S
Max. pressure
Max. temperature
K value [m 3 /h]
VS
M A T E R I A L S
Valves and fittings
Gaskets
Insulation
5 . 1 D I F F E R E N T I A L P R E S S U R E
D I A G R A M
Flow rate [l/h]
125 mm
250 mm
385 mm
340 mm
1" int. thread
1½" ext. thread
¾" ext. thread x 110 mm or 1" ext. thread x 130 mm
19.6 mbars, can be opened
6 bars
110 °C
6.3
Brass / POM
EPDM
EPP
2 5
