1.8

Electrical current

There is a danger of an electric shock when working with
electrical current. Therefore:
• Switch off the power before beginning work on the pump
and make sure that it cannot be switched on again acciden-
tally.
• Do not kink or nip the power cable or allow it to come into
contact with heat sources.
• The pump is protected against drips in accordance with
protection class IP 42. Protect the pump against water
spray. Do not immerse in water or other fluids

2 Technical Data

2.1 Type key
COSMO Series:
Standard secondary hot water circulation pump,
glandless pump
CPZ Type designation:
A = with check valves
2.2 Connections (Fig. 1)
COSMO CPZ (Fig. 1a)
Screwed connection: 15 (Rp ½")
COSMO CPZ A (Fig. 1b)
Screwed connection: 15 (Rp ½") and check valves
Installation and operating instructions
English
13
