Installation

NOTE:
The following drawings refer to the
ent variants vary in the number of dynamic ports and the transmission medium
(CAT/Fiber) to connect user modules and target modules.
The following pages describe the installation of the devices of the KVM system.
NOTE: When choosing a place for the device, please ensure to comply with the
ambient temperature limit (see Technical data on page 31) close to the device. The
ambient temperature limit must not be influenced by other devices.

Power supply

18 20 22
24
17 19 21 23
Plug one of the supplied power cable in this interface. Connect the
Main Power:
power cable with a power outlet and turn the power button on.
Red. Power: If required, plug one of the supplied power cable in this interface to
establish a redundant power supply. Connect the power cable with a power outlet of
another power circuit and turn the power button on.
ControlCenter-Compact-16F16C
26 28 30 32
25 27 29 31
Main Power Main Power
Power
Red.
Main
Status Ident.
Portfunction
Fail
G&D ControlCenter-Compact · 8
Installation
. The differ-
Red. Power Red. Power
