Creating a new channel group

How to create a new channel group:
1. In the menu, click on
2. Click on a console or a target module that is not assigned to a channel group.
3. Click on
Channel grouping
The selected module is assigned to the first KVM channel and is shown in the
Device group column. The right column (
ules you can add to the new channel group.
NOTE: You can assign up to seven additional video channels, one USB or
RS232 channel and four multi channels to a console's KVM channel.
You can assign up to seven additional video channels to the KVM channel of the
computer, too. In addition, you can create
RS 232 channel and for each of the four multi-channels.
NOTE:
All channels of a channel group are switched at the same time.
4. In the right column (
column ( Device group
NOTE: To change the order of already added channels, mark a channel and
click on (arrow down) or
down.
5. Click on (arrow left) to assign the module to the chosen channel.
6. Repeat steps 4 and 5 to add another module to the channel group.
7. Click on Save .
Matrix systems > [Name] > User modules
.
Unassigned
Unassigned ), click on the module you want to add. In the left
), click on the channel you want to add the module to.
(arrow up). The chosen channel is moved up or
Expanding switchable signals
or Target modules
) lists the matrix switch mod-
pools of four devices for the USB 2.0/
