Cascading a matrix switch

Cascading allows you to increase the number of target computers to be connected.
In a cascade, a slave central module is connected to the dynamic ports of a master
central module. These ports must be configured as ports for the connection of target
modules.
You can connect either target modules or further slave central modules (up to 2 cas-
cade levels) to the slave central module.

Configuration and highlighting of port assignment

By default, the matrix switch auto-detects the modules connected to the ports and
configures the ports accordingly.
NOTE: When connecting a user module or a target module, the ports are auto-con-
figured. In case of a cascade, note or change the port mode.
By default, the ports of the different variants of the ControlCenter-Compact series are
configured to connect both master and slave matrix switches:
Variant
ControlCenter-Compact-8C
ControlCenter-Compact-16C
ControlCenter-Compact-16F
ControlCenter-Compact-16F16C
ControlCenter-Compact-32C
ControlCenter-Compact-32F
ControlCenter-Compact-32F-16C
ControlCenter-Compact-32F-32C
ControlCenter-Compact-32F-48C
ControlCenter-Compact-32F-80C
ControlCenter-Compact-48C
ControlCenter-Compact-48F
ControlCenter-Compact-48F-16C
ControlCenter-Compact-64C
ControlCenter-Compact-80C
ControlCenter-Compact-128C
ControlCenter-Compact-176C
Expanding the KVM matrix system by cascading
Up ports
1 to 2
1 to 4
1 to 4
1 to 8
1 to 8
1 to 8
1 to 12
1 to 16
1 to 20
1 to 28
1 to 12
1 to 12
1 to 16
1 to 16
1 to 20
1 to 32
1 to 44
G&D ControlCenter-Compact · 22
Down ports
3 to 8
5 to 16
5 to 16
9 to 32
9 to 32
9 to 32
13 to 48
17 to 64
21 to 80
29 to 112
13 to 48
13 to 48
17 to 64
17 to 64
21 to 80
33 to 128
45 to 176
