Variant
ControlCenter-Compact-64C
ControlCenter-Compact-80C
ControlCenter-Compact-128C
ControlCenter-Compact-176C
Use the dynamic ports to connect either user modules or target modules.

Expanding a KVM matrix system

If the number of ports of a matrix switch is not sufficient for the desired purpose,
you can combine multiple matrix switches.
For this, we provide the technologies
ject to a charge).
Information about these technologies is given in the chapter Expanding the KVM
matrix system by cascading on page 21.
The »ControlCenter-Compact« KVM matrix system
Dynamic ports to connect modules
64 × RJ45 socket (CAT)
80 × RJ45 socket (CAT)
128 × RJ45 socket (CAT)
176 × RJ45 socket (CAT)
(default) and
Cascading
G&D ControlCenter-Compact · 6
(sub-
KVM Matrix-Grid™
