Technical specification

The following information represents the dimensions and indications of weight and the manu-
facturer's approved machine data. The calculated envisaged life of the machine to EN ISO
13849 and EN ISO 12100 is at least 10 years with a daily operation of 8h at 220 working days
per year when keeping to the ambient conditions, proper use and keeping to the required main-
tenance intervals. Safety-related replacement parts are included in this calculation. Normal
replacement parts such as, for example, bearings or V-belts, are not part of this calculation.
Electrical connection
Spindle drive motor power
Drilling capacity in steel (S235JR) [mm]
Drilling capacity in steel (S235JR) [mm]
Throat depth
Spindle stroke
Spindle seat
Table size
Length x Width of the working surface
Table side tilt / Turning the table
T-slot size
T-slot size / distance / number
Distance spindle - table [mm]
EN
D17 Pro│D23 Pro│D26 Pro│D33 Pro
74
D17 Pro
230V~50 Hz
230V~50 Hz
optional ~60Hz 400V~50 Hz
optional ~60Hz
500 W
Ø 16 mm
Ø 12 mm
152 mm
65mm
MT2
235 x 220 mm 280 x 245 mm
± 45° / 360° ± 45° / 360°
12 mm
diagonal
max. 325 mm max. 425 mm
Translation of original instruction
D23 Pro D26 Pro
or 400V~50 Hz
optional ~60Hz
750 W 750 W
Ø 25 mm Ø 25 mm
Ø 20 mm Ø 20 mm
180 mm 210 mm
80mm 85mm
MT2 MT3
330 x 290 mm
± 45° / 360°
12 mm 14 mm
diagonal diagonal
max. 720 mm
Version 1.0.3 - 2022-04-06
D33 Pro
400V~50 Hz
optional ~60Hz
1.1 kW
Ø 30 mm
Ø 25 mm
254 mm
120mm
MT4
475 x 425 mm
± 45° / 360°
14 mm
diagonal
max. 695 mm
