11. Disposal and recycling

The equipment is supplied in packaging to prevent it
from being damaged in transit. The raw materials in
this packaging can be reused or recycled.
The equipment and its accessories are made of vari-
ous types of material, such as metal and plastic. De-
fective components must be disposed of as special
waste. Ask your dealer or your local council.
Old devices must not be disposed of with house-
hold waste!
This symbol indicates that this product must
not be disposed of together with domestic
waste in compliance with the Directive
(2012/19/EU) pertaining to waste electrical
and electronic equipment (WEEE).

12. Troubleshooting

Fault

Possible cause

No supply voltage.
Insufficient supply voltage.
The compressor does
not start.
Outside temperature is too low.
Motor is overheated.
The safety valve (8) leaks.
The compressor starts
but there is no pres- The seals are damaged.
sure.
The drain plug for condensation water (10)
leaks.
The hose connections have a leak.
The compressor
starts, pressure is
shown on the pressure A quick-lock coupling has a leak.
gauge, but the tools
do not start.
Insufficient pressure set on the pressure
regulator (5).
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
All manuals and user guides at all-guides.com
This product must be disposed of at a designated
collection point. This can occur, for example, by
handing it in at an authorised collecting point for the
recycling of waste electrical and electronic equip-
ment. Improper handling of waste equipment may
have negative consequences for the environment
and human health due to potentially hazardous sub-
stances that are often contained in electrical and
electronic equipment. By properly disposing of this
product, you are also contributing to the effective
use of natural resources. You can obtain information
on collection points for waste equipment from your
municipal administration, public waste disposal au-
thority, an authorised body for the disposal of waste
electrical and electronic equipment or your waste
disposal company.
Remedy
Check the supply voltage, the power plug and
the socket-outlet.
Make sure that the extension cable is not too
long. Use an extension cable with large enough
wires.
Never operate with an outside temperature of
below +5° C.
Allow the motor to cool down. If necessary, rem-
edy the cause of the overheating.
Have a service center replace the safety valve
(8).
Check the seals and have any damaged seals
replaced by a service center.
Tighten the screw by hand. Check the seal on
the screw and replace if necessary.
Check the compressed air hose and tools and
replace if necessary.
Check the quick-lock coupling and replace if
necessary.
Increase the set pressure with the pressure
regulator.
