1. Introduction

Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschine GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
we hope your new tool brings you much enjoyment
and success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified,
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regula-
tions and local regulations.
We recommend:
Read through the complete text in the operating in-
structions before installing and commissioning the
device. The operating instructions are intended to
help the user to become familiar with the machine
and take advantage of its application possibilities in
accordance with the recommendations. The operat-
ing instructions contain important information on how
to operate the machine safely, professionally and
economically, how to avoid danger, costly repairs, re-
duce downtimes and how to increase reliability and
service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regula-
tions that apply for the operation of the machine in
your country. Keep the operating instructions pack-
age with the machine at all times and store it in a
plastic cover to protect it from dirt and moisture.
Read the instruction manual each time before op-
erating the machine and carefully follow its informa-
tion. The machine can only be operated by persons
who were instructed concerning the operation of the
machine and who are informed about the associated
dangers. The minimum age requirement must be
complied with.
In addition to the safety notices contained in this
operating manual and the particular instructions for
your country, the generally recognised technical reg-
ulations for the operation of identical devices must
be complied with.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
All manuals and user guides at all-guides.com
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.
2. Device description (Fig. 1 - 10)
1. Handle
2. Pressure switch
3. ON/OFF switch
4. Pressure gauge (for reading the vessel pres-
sure)
5. Pressure regulator
6. Quick-lock coupling
7. Pressure gauge (for reading the preset vessel
pressure)
8. Safety valve
9. Backflow locking valve
10. Condensation water drain plug
11. Pressure vessel
12. Wheel (2x)
13. Safety sign
14. Oil inlet plug
15. Air filter unit
16. Glass sight gauge for oil level
17. Oil drain plug
18. Overload switch

3. Scope of delivery

• Compressor
• 1x Air filter
• 1x Supporting foot
• 2x Wheel
• 1x Mounting material
• 1x Oil sealing plug (E)
• 1x Oil bottle
• 1x Translation of Original Operating Manual
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the
packaging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for trans-
port damage.
• If possible, store the packaging until the warranty
period has expired.
m ATTENTION
The device and packaging materials are not toys!
Children must not be allowed to play with plas-
tic bags, film and small parts! There is a risk of
swallowing and suffocation!
