VIEWEG
This is shown in the example as follows:
In order to obtain the time curve based on the measurement range/ duration, the con-
version Value must be made to time increments . There are 10000 measurement points
for each measurement, independent of the measurement range of time . So the time
increment between two measuring points is Duration /10000 .
EN
Values
Upper Limit
CH1
(+20%)
925
1194
941
1185
917
1210
922
1204
918
1207
926
1220
6 Updates
The current software version is displayed both when the device is started (on the start
screen in the lower left corner) and under Settings . To install a new software, use the
USB stick included in the delivery (2 GB, formatted in the file system FAT, 32kB) and only
install the provided file update . b in - no further directories or files! Insert this prepared
USB stick into the USB interface of the QC-100 and restart the device by disconnecting
and reconnecting the power supply .
When booting up via the software update, the update . b in file is recognized and the
update is accepted .
The activity of the QC-100 is displayed in the upper left corner, as during the start-up
process .
Lower Limit
Values
Upper Limit
(-20%)
CH2
(+20%)
582
3
12
573
7
8
598
9
11
592
7
10
595
15
8
608
8
14
Operating Manual QC-100 quality control
Lower Limit
Ref1
(-20%)
8
4
7
6
4
10
44
Duration
Measurement
00005000 ms
NOK
