Before overwriting, the Security question
<Replace reference?> to prevent unintentional
overwriting .
Operating Manual QC-100 quality control
Color indicators behind the respective Ref 1 to
Ref 4 indicate the status:
Red = inactive, green = active .
The following procedure must be carried out to
store measured values:
- Set the memory location by tapping the
buttons Ref 1 to Ref 4 .
- The color indicator changes to green if
necessary . In this example Ref 4 .
- After starting the dispensing process, the
measurement data are displayed in the form
of a measurement curve .
- When the dispensing process is complete,
tap the <Set reference> button to save it to
the previously selected memory location .
Acknowledge the notification and overwrite
the possibly already stored reference with the
new one .
Reference curves can be stored on a USB me-
mory stick and call them up again from there .
To do this, call up the diskette symbol .
38
NOTICE
