Operating Manual QC-100 quality control
VIEWEG
If EASY is selected as the start condition in the
Settings menu item, the Play icon is added
to the screen . When pressing, this changes to
Pause and the display of the measurement data
is permanent without further start conditions .
EN
This function makes it possible to display the
pressure curve easily, whereby no evaluation of
blocks takes place here . When pressing Pause,
this changes to Play and the current measure-
ment runs until the end of the measurement
period .
Opposite you see an exemplary example for
the monitoring of / with two pressure sensors .

5.4 Menu Log-File

In the menu item "Log-File" you can get infor-
mation about the last messages and errors .
The screen is divided into two areas:
Log-File "last measurements" and "last errors
(USB data)" .
In the area Log-File last measurements the eva-
luation results of the last 15 measurements are
symbolized, whereby the most recent measure-
ment is in the upper left corner .
