Operating Manual QC-100 quality control
After approx . 10 seconds, the Welcomescreen appears . After a further 15 seconds, the
device displays the QC-100 start screen .
Once the start-up process is complete, the measurement curve screen appears with the
default values or the last settings used as well as the last selected reference curve .
The device is now ready for recording measurement data .
By tapping the Home button, you can access the main menu .
The following instructions mainly refer in pictures and
description to the use with one channel . In the case
of the setting for the use of 2 channels in parallel, the
graphic display is extended by this .

5.1 Settings menu

This shows four buttons with which you can
access the submenus namely:
Measurement, Settings, Log File and Teach-In .
In each submenu, the name of the current
menu is displayed in the upper left corner of
the screen .
In the menu item Settings the possible
Basic settings displayed on five different menu
pages .
