SAFETY INFORMATION

•
No smoking! No open fire or heat sources!
•
The product was developed, manufactured and
inspected according to the basic safety requirements
of EC Guidelines and state-of-the-art technology.
•
The instrument is designed for use in grounded
vehicles and machines as well as in pleasure boats,
including non-classified commercial shipping.
•
Use our product only as intended. Use of the product
for reasons other than its intended use may lead to
personal injury, property damage or environmental
damage. Before installation, check the vehicle
documentation for vehicle type and any possible
special features!
•
Use the assembly plan to learn the location of the
fuel/hydraulic/compressed air and electrical lines!
•
Note possible modifications to the vehicle, which
must be considered during installation!

SAFETY DURING INSTALLATION

•
During installation, ensure that the product's
components do not affect or limit vehicle functions.
Avoid damaging these components!
•
Only install undamaged parts in a vehicle!
•
During installation, ensure that the product does not
impair the field of vision and that it cannot impact the
driver's or passenger's head!
•
A specialized technician should install the product. If
you install the product yourself, wear appropriate
work clothing. Do not wear loose clothing, as it may
get caught in moving parts. Protect long hair with a
hair net.
•
When working on the on-board electronics, do not
wear metallic or conductive jewelry such as
necklaces, bracelets, rings, etc.
•
If work on a running engine is required, exercise
extreme caution. Wear only appropriate work
clothing as you are at risk of personal injury, resulting
from being crushed or burned.
•
Before beginning, disconnect the negative terminal
on the battery, otherwise you risk a short circuit. If the
vehicle is supplied by auxiliary batteries, you must
also disconnect the negative terminals on these
batteries! Short circuits can cause fires, battery
explosions and damages to other electronic systems.
Please note that when you disconnect the battery, all
WARNING
•
To prevent personal injury, property damage or
environmental damage, basic knowledge of motor
vehicle/shipbuilding electronics and mechanics is
required.
•
Make sure that the engine cannot start
unintentionally during installation!
•
Modifications or manipulations to veratron products
can affect safety. Consequently, you may not modify
or manipulate the product!
•
When removing/installing seats, covers, etc., ensure
that lines are not damaged and plug-in connections
are not loosened!
•
Note all data from other installed instruments with
volatile electronic memories.
volatile electronic memories lose their input values
and must be reprogrammed.
•
If working on gasoline boat motors, let the motor
compartment fan run before beginning work.
•
Pay attention to how lines and cable harnesses are
laid so that you do not drill or saw through them!
•
Do not install the product in the mechanical and
electrical airbag area!
•
Do not drill holes or ports in load-bearing or
stabilizing stays or tie bars!
•
When working underneath the vehicle, secure it
according to the specifications from the vehicle
manufacturer.
•
Note the necessary clearance behind the drill hole or
port at the installation location. Required mounting
depth: 65 mm.
•
Drill small ports; enlarge and complete them, if
necessary, using taper milling tools, saber saws,
keyhole saws or files. Deburr edges. Follow the safety
instructions of the tool manufacturer.
•
Use only insulated tools if work is necessary on live
parts.
•
Use only the multimeter or diode test lamps
provided, to measure voltages and currents in the
vehicle/machine or boat. Use of conventional test
SAFETY INFORMATION
