Adjusting the rip
fence
Switching the
machine on and
off
Advices for
operation
ENGLISH
Slacken the wing-nut and set the rip fence
to the required cutting width by means of
the cutting line scale. Retighten wing-nut.
For safety reasons this power tool is fitted
with a switch lock and the On-/Off switch
cannot be locked in the "On" position.
Switching on: Press the switch lock
forwards, and then press the On-/Off
switch.
Switching off: Release On-/Off switch
1.
Switch on the machine and apply to the material with the front edge of the guide
plate.
2.
Align the tool with the parallel guide or a line drawn by hand.
3.
Hold the tool firmly by both handles and work applying light pressure.
When sawing along a line use the cutting information shown in the window according
to the cutting angle.
– right–angled cut
o
– 45 cut
For bevel cuts the guide (i.e. parallel guide, ridge) must be applied shifted to scale
(carry out a test cut).
The parallel guide allows a max. cutting width of 250 mm. For wider cuts use an
guide bar (accessory) or lead the tool along a fixed ridge.
To avoid a tearing out of the cutting edges when working sensitive material (i.e.
coated chip boards) stick some crepe tape onto the area to be cut (if the surface is
very smooth crepe tape also enables easy drawing of lines). Fixing a thin board of
wood to the workpiece and sawing through both will also avoid tearing out effectively.
4
– indicator on "0"
– indicator on "45"
HK 46 N
