11
Disposal
Dispose of packaging material in an environmentally friendly way
and in accordance with the applicable local disposal regulations.
The symbol with the crossed-out waste bin on waste elec-
trical or electronic equipment stipulates that this equipment must
not be disposed of with the household waste at the end of its life.
You will find collection points for free return of waste electrical
and electronic equipment in your vicinity. The addresses can be
obtained from your municipality or local administration. The sep-
arate collection of waste electrical and electronic equipment aims
to enable the re-use, recycling and other forms of recovery of
waste equipment as well as to prevent negative effects for the en-
vironment and human health caused by the disposal of hazard-
ous substances potentially contained in the equipment.
12
Declaration of conformity and incorporation
Declaration of Incorporation in accordance with the
EC Machinery Directive 2006/42/EC
Manufacturer's declaration of incorporation
(translation of the original)
For the installation of partly completed machinery in terms of the
EC Machinery Directive 2006/42/EC, Annex II Part 1 Section B
We hereby declare that the following partly completed machinery
– as far as possible with respect to the scope of supply –
complies with the essential requirements of the EC Machinery
Directive. The partly completed machinery is only intended to be
incorporated into a door system in connection with the door
drives specified below, to thus form a complete machine within
the meaning of the EC Machinery Directive. The door system
must not be put into service until the final machinery has been
declared in conformity with the provisions of the EC Machinery
Directive and the EC Declaration of Conformity according to
Annex II A is available. We furthermore declare that the relevant
technical documentation for this partly completed machinery has
been compiled in accordance with Annex VII, Part B, and
undertake to transmit it through our Documentation Department
in response to a reasoned request by the competent national
The EC type-examination procedure described in Annex IX was
performed by the approved testing laboratory
TÜVNORDCERT GmbH (NB 0044), Langemarckstr. 20,
45141 Essen.
EC type examination certificate 44 780 13108301
Product model / product:
Product type:
Year of manufacture from:
Suitable for door drives:
Relevant EU directives:
•
2014/30/EU
•
2011/65/EU RoHS Directive including Annex II according to
(EU) 2015/863
30 - EN
authorities.
T100 R
Door control
01/2021
NovoShaft 9.15 / 9.20 / 9.24 /
14.15 / SI8.120 / SI20.90 /
SI35.60 / SI4,5.90
Fulfilled requirements of the EC Machinery Directive 2006/42/
EC, Annex I, Part 1:
•
1.1.2, 1.1.3, 1.1.5, 1.2.1, 1.2.2, 1.2.3, 1.2.4, 1.2.5, 1.2.6,
1.3.2, 1.3.4, 1.5.1, 1.5.2, 1.5.4, 1.5.5, 1.5.6, 1.6.2, 1.6.3, 1.7
Applied harmonised standards:
•
EN ISO 12100:2010
•
EN 12978:2003+A1:2009
•
EN 13241:2003+A2:2016
•
EN ISO 13849-1:2015, PL "C" Cat. 2
•
EN 60335-1:2012/AC:2014
•
EN 61000-6-3:2007 / A1:2011
•
EN 61000-6-2:2005 / AC:2005
Other applied technical standards and specifications:
•
EN 12453:2019
•
EN 300220-1:2017-05
•
EN 300220-2:2017-05
•
EN 301489-1:2017
Manufacturer and name of the authorised representative of
the technical documentation:
Novoferm tormatic GmbH
Eisenhüttenweg 6
44145 Dortmund
Place and date of issue:
Dortmund,
23.11.2020
Dirk Gößling, Managing Director
Declaration of Conformity according to Directive
2014/53/EU
The integrated radio system complies with directive 2014/53/EU.
The full text of the declaration of conformity can be found at:
https://www.tormatic.de/dokumentation/
13
Inspection
When being commissioned, power-operated doors must be in-
spected and maintained by correspondingly qualified persons
(persons with suitable qualifications, based on knowledge and ex-
perience) and in compliance with intervals specified by the manu-
facturer in the maintenance instructions and, if necessary, also in
accordance with any special national regulations (e.g. ASR A1.7
"Technical Rules for Workplace Safety - doors and gates"). All
maintenance and inspection tasks must be documented in the in-
spection logbook provided. It must be kept safe by the operating
company, together with the documentation of the door system,
throughout the entire service life and must be handed over to the
operating company in a duly completed fashion, at the latest on
the date of commissioning by the technician. (We also recom-
mend this for manually operated doors.) The specifications laid
down in the documentation of the door system (assembly, operat-
ing and maintenance instructions, etc.) must be absolutely ob-
served in any case.
The manufacturer's warranty expires immediately if the inspec-
tion / maintenance has not been carried out properly!
Any changes that are made to the door system (if permitted at all)
must also be documented.
T100 R
