10. Door connection box
a
Fig. The door connection box allows for the connection of a
safety edge, a wicket door contact and slack rope switches. The
wicket door contact and the slack rope switches are electrically
connected in series and are monitored by the control. If a wicket
door is available, the wicket door contact (Entrysense 6k8 model)
is connected to the door connection box. For this purpose, re-
move the 2 kOhm resistor from the door connection box, to which
the Entrysense is clamped, and connect it there. The Entrysense
is tested in compliance with PL c as per EN 13849-1 and is mon-
itored by the door control.
As slack rope switches, switches with forced actuation complying
with the specifications of EN 60947-5-1, Annex K are to be used.
The supply line of the door connection box is to be laid at the
door leaf, well protected against damage. With pulsed operation,
connect a closing edge safety device and select the correspond-
ing setting in menu item 35. Pressing the Prog button
menu item 35 for a longer time displays the measured resistance
value of the 8k2 closing edge. Example: Value 82 means 8k2.
Pressing the Prog button
Crush hazard and risk of being struck by the
CAUTION
closing door
The pressure wave switches may only be actu-
ated after having been tested.
• For this purpose, select the value 2 in menu
item 35.
b
Fig. Connect a door connection box with a break-away sensor
and an OSE (optical closing edge safety device).
c
Fig. Connect a door connection box with a break-away sensor
and an 8k2 closing edge safety device).
When using a RadioSafe module, a light grid or another
safety solution, connect the 8k2 resistor directly to terminal J3.
Value 1 has to be selected in menu item 35.
11. Light grid
Instead of the closing edge safety device, the following light grids
can be connected:
a
Fig. A light grid by Telco with "SG14" testing. Set the value
to 1 in menu item 36.
b
Fig. A light grid by Telco with "SG15" OSE interface. Set the
value to 0 in menu item 35.
c
Fig. A light grid by CEDES with "GridScan/Mini-SB-2" OSE in-
terface. Set the value to 0 in menu item 35.
d
Fig. A light grid by WITT with "LIGI" OSE interface. Set the
value to 0 in menu item 35.
12. Photoelectric sensor
Connect the photoelectric sensor as specified for the following
variants:
a
Fig. 2-wire photoelectric sensor LS2
b
Fig. 4-wire photoelectric sensor LS5 with testing
c
Fig. Reflection light barrier
Then select the corresponding photoelectric sensor under menu
item 36.
If you have selected "Photoelectric sensor mounted in the frame",
the next CLOSE run executed by the control is a "learning cycle"
for detecting the position.
Do not interrupt the learning cycle
NOTICE
The learning cycle must not be interrupted, so
that no incorrect position is recorded.
briefly will interrupt the display.
13. Anti crash sensor
Via a connected anti-crash sensor, input J6 detects when the cur-
tain is off guide and starts automatic threading up.
a
Fig. One-way light barrier with relay output (SMR32xx /
SMT30xxC)
b
Fig. One-way light barrier with transistor output (ELS-300 NO)
14. STOP circuit
a
Fig. Emergency stop connection
Connect the emergency stop button to terminal J4.3/4.
b
Fig. Connection of the roll-up protection mechanism
To provide for protection from being drawn in, with fixed cable
routing a roll-up protection mechanism with an evaluation unit can
be connected to the safety circuit J4.3/4. The evaluation unit must
comply with PL c Cat3 as per EN 13849-1.
Also use this input to connect a spring break switch.
in
15. Key switch
When connecting a key switch to the connection terminal J7
a
(Fig. ), the control has to be programmed accordingly. Select
the desired function in menu item 50 "Key switch function".
16. Radio receiver
For the use of a hand-held transmitter, attach the receiver module
a
(option) to J11 (Fig.
to program the hand-held transmitters, follow the instructions
provided in Programming a radio hand-held transmitter in the
Programming chapter.
17. Relay outputs
The control provides two potential-free change-over contacts
(250 V AC / 2 A, 24 V DC / 1 A).
The 24 V output at terminal X8 may be loaded with a maximum of
700 mA.
Select the desired relay function in menu items 45 and 46.
a
Fig. Connection of a red-green signaller. Select the value 0 in
menu item 45 and the value 1 in menu item 46.
b
Fig. Example: pre-warning time / acoustic signal
c
Fig. Connection for the mutual locking of 2 doors (lock circuit).
Select the value 2 or 3 in menu item 50 and the value 0 in menu
item 45.
d
Fig. Connection for the mutual locking of 3 doors (lock circuit).
Select the value 2 or 3 in menu item 50 and the value 0 in menu
items 45 and 46.
T100 R
) and connect the antenna to J12. In order
