TECHNICAL DATA

Traction unit
Design
Dispensing speed
Maximum predispensing of labels
Minimum passing width
Maximum passing width
Minimum label length
Stop tolerance
Minimum distance between goods
Unwinder
Maximum diameter of label roll
Diameter of corn
Maximum weigth of label roll
Rewinder
Drive
Power supply
Power input
Tolerated surrounding temperature
Tolerated surrounding humidity
Dimensions (W / H / D)
Weigth
Supplied accessories
Peripheral devices
Fix dispensing edge 95 / 160
Flap adapter 95 / 160 spring mounted or with magnet
Goods scanner by infra-red or polarized light
Mechanical switch to detect gap between goods
Optical or mechanical label scanner
5999.522-01A 09.07.2001 WM
We reserve the right to make design modifications
®
Collamat 7610
right / left
3 to 50 m/min
100 mm
10 mm
95 mm
10 mm
± 1 mm
approx. 5 mm
Diameter 250 or 350 mm, with suspended spring and
automatic roller brake
250 / 350 mm
42 mm
10 kg
Takes up the carrier paper of a label reel of diameter
250 mm
3-phase steppermotor
110 / 120 V oder 220 / 230 / 240 V
+10 / -15 % , 50 / 60 Hz
280 VA
0 to 50 °C
15 to 90 % , non-condensing
approx. 266 x 245 x 288
mm
approx. 11,4 kg
5 mm hexagon socket spanner with handle
®
Collamat 7620
right / left
3 to 50 m/min
100 mm
10 mm
160 mm
10 mm
± 1 mm
approx. 5 mm
250 / 350 mm
42 mm
10 kg
approx. 266 x 245 x 353
mm
approx. 11,6 kg
Seite/Page 15 / 18
