1. In the menu, click on
2. Click on the computer module (CPU) you want to configure and then
click on Configuration
3. Click on the tab General
4. Click on the tab
CPU
RS232 interface of the computer module.
Click on the tab CON
RS232 interface of the console module.
5. Select one of the options of the
graph Configuration :
RS232  The data stream of an RS232 device is transmitted from the
computer module to the console module (default setting).
RS422  The data stream of an RS422 device is transmitted from the
computer module to the console module via separately
available
6. Click on .
Save
KVM extender .
.
.
if you want to adjust the operating mode of the
if you want to adjust the operating mode of the
Serial communication
G&D RS232-422 adapters
field under the para-
.
G&D VisionXS-IP-F-DP-UHR · 36
Configuration
