Configuration

The configuration of the KVM extender can be changed either using the on-screen
display (OSD) or the web application
 The on-screen display is shown on the console monitor. Most configuration settings
can be changed directly on the OSD of the console.
 The web application
and monitor the KVM extender via web browser.

Overview of functions and default settings

The following table provides an overview of the configurable functions of the KVM
extender. It additionally lists the default settings and references to detailed descrip-
tions of the functions.
Function
Changing hotkeys
Changing the OSD key
Opening the on-screen display via double keypress
Adjusting the operating mode of the RS232 interface
Selecting the EDID mode of the KVM extender
Reducing the colour depth of the image data to be transmitted 24 bit
Freeze mode
Enabling or disabling DDC/CI support
(De)Activating an USB keyboard or the »Generic USB« mode
Changing the scancode set of PS/2 keyboards
Reinitialising USB input devices
Adjusting the waiting period of the screensaver
Selecting a keyboard layout for inputs via OSD
Resetting the default settings
Resetting the netfilter rules
Config Panel
provides a graphical user interface to configure
Config Panel
:
Default setting
Ctrl
Num
turned off
RS232
auto
disabled
disabled
PC Multimedia
scancode set 2
only faulty devices
disabled
German
