STEP 6.
Install the cover (22) onto the handlebar post (25).
Connect the computer cable (24) to the connecting
cable (23).
Fix the handlebar post (25) to the main frame (1) with
cross-head bolts (21), flat washers (39), and curved
washers (40).
Slide the handlebar post cover on (22).
STEP 7.
Install the water bottle holder (44) on the handlebar
post (25) using the bolt (45) and the flat washer (46).
Make sure the holder is secure and insert the bottle.
STEP 8.
Plug in the power supply unit (41) and plug the cable
into the power socket on the front of the mainframe.
Congratulations!
You have assembled magnetic bike!
Read the manual carefully before using the bicycle.
ADJUSTMENTS
Handlebar adjustment
Loosen the handlebar adjustment knob. Set the handlebar in the desired position and tighten the knob.
Make sure the handlebar is secured.
Saddle height
Loosen the adjustment knob. Set the saddle at the right height and tighten the knob. Make sure the saddle is
secured.
Saddle position
Loosen the saddle guide knob. Set the saddle to the desired position and tighten the knob. Make sure the
saddle is secured.
Adjusting pedal straps
Fix the side of the rubber strap with three holes to the internal part of the pedal. Fix the other end to one of
the adjustment opening so that the feet is fixed during training and easy to take out. Repeat for the other
pedal.
MAINTENANCE
Carry out maintenance activities at regular intervals.
The tasks listed below should be carried out at least every 20 hours of operation.
•
Check moving parts of the device. If they need lubrication, use a bicycle bearing grease.
• Check the conditions of such parts as bolts and nuts. Make sure they are tight.
• Wipe the sweat off the device after each training. Make sure the display does not come in contact
with water or moisture.
• Clean the product with soapy water only. Do not use cleaning agents.
