Camera assembly

Note
Connect the camera only with the endoscope locked in
the working trocar!
Secure the endoscope 5 in the MINOP inVent tro-
car 1, see Fig. 2.
When doing so, ensure that the locking pin 6 of the
endoscope 5 is on the same side as the release
button 3 of the MINOP inVent trocar 1.
5
Fig. 2
6
3
1
Connect light cable and camera, see Fig. 3–5.
5
1
Fig. 3
5
1
Fig. 4
5
