Water pressure and temperature
The cleaning attachment should be charged up to max. 200 bar. Make sure that the hose connection is tight (O-rings in
the connection thread) and never cover escaping water with any part of your body! In order to prevent damage, select a
water pressure on the high-pressure cleaner that is suitable for the substrate.
CAUTION
The max. preset water temperature should not exceed 80° C. A temperature monitor switches off the suction unit and
the integrated immersion pump in the event of excessive temperature. Allow the system to cool down for approx. 15
minutes and then switch the suction unit and immersion pump back on. For more effective cooling, please open the
suction unit by removing the suction basket from the lower barrel.

Cleaning attachment:

CAUTION
Never look or reach into the attachment! Risk of injury! The height of the sealing brushes can be adjusted by loosening
the outer screws. When working on smooth substrates the sealing brushes should be retracted as far as possible. When
working on rough substrates the sealing brushes should be extended in accordance with the depressions in the substra-
te. Adjust the sealing brushes in such a way that no water escapes from the cleaning attachment and that a light, fluid
movement of the attachment is possible over the substrate.
Make sure that the inside of the cleaning attachment is free of soiling that could prevent the rotating nozzles from turning.
Before starting work, check that water is exiting both nozzles on the rotating head, and that the water pressure is turning
the head in the cleaning attachment (never switch on the high pressure cleaner to do this).
CAUTION
Never look into the cleaning attachment from the side and never look directly into the rotating nozzle while actuating
the hand valve! If water is not ejected smoothly from the nozzles, it may mean they need cleaning. In order to do this,
use an 8 mm flat spanner to remove the two nozzles from the supporting arms, and carefully clean the inner bores.
Actuate the hand valve again to flush out any particles that have been clogging the supporting frame. Then reattach the
nozzles and use the spanner to tighten the connections.
Remove any soiling that has built up on the roller bearings if the roller bearings do not turn easily.
Note:
Regular cleaning, maintenance and servicing after completing work will help avoid downtime!

Suction hose:

The max. suction hose length must not exceed 30 m. Do not use a longer hose than necessary. Make sure that the hose
is always laid out straight without „sag" or kinks.
When you have finished using the machine flush the hose thoroughly to prevent clogging. When working on scaffolding,
we recommend you hang the hose on the scaffolding with hose clamps (art. no. 64 24 25) for strain relief.

Suction unit with immersion pump:

The suction basket is equipped with a vacuum flow interrupter which interrupts the flow if an excessive amount of soiling
has built up in the filter basket, preventing water exiting the filter basket so that the water level in the filter basket has
reached the max. level.
63 Translation of the original instruction
