• Devices and systems that are compromised by the
interference radiation must be removed from the
welding area or shielded.
• Using an electromagnetic filter that reduces elec-
tromagnetic interference.
General safety information
It is the user's responsibility to install and use the
equipment properly in accordance with the instruc-
tions issued by the manufacturer. If electromagnetic
interference is noticed, it is the user's responsibility
to eliminate said interference with the technical de-
vices mentioned in the section "Important information
about the power connection".
Reduction of emissions
Main current supply
The welder must be connected to the main current
supply in accordance with the instructions issued by
the manufacturer. If interference occurs, it may be
necessary to introduce additional measures, e.g. fit-
ting a filter to the main current supply (see above in
the section "Important information about the power
connection"). The welding cables should be kept as
short as possible.
Warning! This power tool generates an electromag-
netic field during operation. This field can impair ac-
tive or passive medical implants under certain condi-
tions. In order to prevent the risk of serious or deadly
injuries, we recommend that persons with medical im-
plants consult with their physician and the manufacturer
of the medical implant prior to operating the power tool.

5. Proper use

This welding device is suitable for welding metals
such as carbon steel, alloy steel, other stainless
steels, copper, aluminium, titanium etc. The product
has an indicator lamp, heat protection indicator and
cooling fan. It is also equipped with a carrying strap
for safe lifting and moving of the product.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the manufacturer
will be liable for any damage or injuries of any kind
caused as a result of this.
The device may only be operated by qualified or in-
structed personnel. This includes persons who, due
to their technical training, experience and knowledge
of the relevant facilities, are able to assess the work
assigned to them and recognize possible dangers or
persons who are responsible for the assigned work
and have been instructed about possible dangers
due to careless behaviour.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial ap-
plications. Our warranty will be voided if the machine
is used in commercial, trade or industrial businesses
or for equivalent purposes.
24 | GB

6. Technical data

Mains voltage U
Off-load voltage U
Working voltage U
Welding current l
Duty cycle X
Energy efficiency of
the power source
Power consumption
in no-load condition
Safeguarding
Protection category
Insulation class
Type of cooling
Welding wire Ø
Weight of the welding
wire reel
weight
Subject to technical changes!
Duty cycle X
Based on a ten minute period for example, this means
that it is permitted to weld continuously at 60% for
six minutes and then the machine must be allowed to
cool for four minutes.

7. Montage

Installing the welding shield (Fig. 2 + 3 + 4 + 5)
• Place the ancillary glass (20) in the recess in the
welding mask. Then place the protective glass (21)
on the ancillary glass and fasten it in place with the
plastic frame (17).
• Fasten the frame in place by turning the fasteners
(3a).
• Fasten the handle (19) onto the welding mask using
the three knurled screws and nuts (18).
Installing the welding wire reel (fig. 6 - 13)
• Open the cover for the wire feeding device (8) by
turning the lock (6) clockwise and folding the cover
upwards.
• Now you can see the wire feeding device and the
welding wire reel (fig. 7).
• Unlock the reel mounting by turning it 90° counter-
clockwise and then pull it off the shaft.
• Remove all packaging from the wire reel (10) so
that it can unroll freely.
• Fit the wire reel (10) onto the reel mounting. Ensure
that the reel will unwind on the same side as the
wire guide (7c).
• Now press the adjusting screw (7b) upwards and
slide the pressing roller (7a) to the side (Fig. 9).
• Unscrew cover (7d) to check the feed roller (10a).
• The corresponding wire thickness is marked
on the top side of the feed roller (fig. 10).
www.scheppach.com
230V~ / 50 Hz
1
0
16,25 - 18,5V~
2
45 - 90 A
2
90 A ~ 10%
45 A ~ 60%
0,6 - 0,9 mm
max. 1 kg
12.5 kg
31V~
65%
18W
16A
H
IP 21S
AF
