7 Connections of deactivation unit

Connection
PE
1
2
EN
The range is generally reduced by metal surfaces. You
will achieve a higher range if you use FH cylinders. Fire
resistant doors are made out of metal and rather thick.
Thus, the electronic thumb-turn of FH cylinders has a
plastic grip element to optimize radio transmission.
This also optimizes transmission from and to the block
lock.
Meaning
Connection for cable shield
Supply voltage (+V)
Supply voltage (ground)
7. Connections of deactivation
unit
25 / 100
