Cleaning the ploughshare
Clean the ploughshare to remove any debris, mud, peat,
plant residues etc that may have built up during use.
UN41-0414FL
Proceed as outlined below.
1) Lift the work vehicle off the ground.
2) Loosen the wing nut (A).
3) Turn the lock lever (B).
4) Push the share forwards and turn it so it is facing
downwards.
5) Clean the ploughshare with the tool provided (C).
Tyre check
Check the tyres for wear and if they feature tears or signs
of ageing, they must be replaced.
Cleaning the work vehicle
Clean the work vehicle with a high-pressure water jet
and, if necessary, with approved detergents.
The liquid used for washing could be hazardous for the
environment due to the presence of pollutants such as
English language
MAINTENANCE INFORMATION
Lack of cleaning will limit the ejector range, there-
fore, as well as affecting the machine's operation, it
also causes serious mechanical damage.
A
B
6) After cleaning, refit the ploughshare in the work posi-
tion.
7) Check that the Plant Control device (D) is inside the
ploughshare.
8) Make sure that the share is secured in place with the
lock lever (B).
9) Tighten the wing nut (A).
Check and if necessary restore the tyre pressure (see the
"Technical characteristics" table).
detergents, oils, etc., therefore do not simply dump the
wastewater; dispose of it in suitable areas equipped with
separation devices for the pollutants.
Dry with compressed air and lubricate the components
shown (see "Lubrication points diagram").
31
D
C
