Seat positioning
Poor work posture will tire the operator and could lead
to mistakes being made; therefore, before starting work,
adjust the seat and secure it in the position that offers
maximum comfort.
Proceed as outlined below.
1) Loosen the screws (A) and adjust the seat height.
2) Tighten the screws (A) to secure the seat in the right
position.
3) Loosen the nut (B) to move the seat lengthways in
relation to the vehicle.
4) Tighten the nut (B) to secure the seat in the right po-
sition.
Using the inserts and extensions
- The inserts (A) are used to keep small seedlings verti-
cal in the dispenser unit and to ensure that they fall
vertically into the ploughshare.
Proceed as outlined below.
1) Fit the inserts (A) inside the cups of the dispenser.
- The extensions (B) are used to keep seedlings with de-
veloped leaf apparatus in vertical position.
Proceed as outlined below.
1) Fit the extensions (B) inside the cups of the dispens-
ing unit.
NOTICE
The inserts must be fitted inside the cups of the dis-
pensing unit instead of the extensions or vice versa.
Planting procedure
The seedlings must be planted in soil which has been
finely tilled with a harrow or hoeing machine and lightly
compacted on the surface.
We recommend you dampen the root ball well (but with-
out causing dripping) to help the seedling fall from the
dispenser better and also take root.
We recommend you dampen the root ball well (but with-
out causing dripping) to help the seedling fall from the
dispenser better and also take root.
English language
INFORMATION FOR USE
UN41-0399FL
B
UN41-0404FL
Do not work on extremely spongy spoil, or extremely
compact soil, nor on very wet ground, as these condi-
tions would all affect planting quality negatively.
During planting, the driving wheels of every planting
unit must grip the ground at all times and the tractor lift
must be fully lowered.
