No. Description
1
Chassis/Waterpump Fan Connector (CHA_FAN1/WP)
2
CPU Fan Connector (CPU_FAN1)
3
ATX 12V Power Connector (ATX12V1)
4
2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
5
ATX Power Connector (ATXPWR1)
6
USB 2.0 Header (USB_56)
7
USB 3.2 Gen1 Header (USB3_12)
8
SATA3 Connector (SATA3_1)
9
SATA3 Connector (SATA3_0)
10
SATA3 Connector (SATA3_3)
11
SATA3 Connector (SATA3_2)
12
Front Panel Type C USB 3.2 Gen2 Header (F_USB3_TC_1)
13
System Panel Header (PANEL1)
14
Chassis Speaker Header (SPEAKER1)
15
Chassis Fan Connector (CHA_FAN2)
16
Front Panel Audio Header (HD_AUDIO1)
17
Clear CMOS Jumper (CLRMOS1)
18
RGB LED Header (RGB_LED1)
19
Addressable LED Header (ADDR_LED1)
2
