DMX operation

Setting the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 15 control channels.
However, it can also be switched to a mode with 10 channels if different functions are required. To be able to
operate the device with a DMX controller, the DMX starting address must be set. The starting address
depends upon which DMX controller is being used. Please refer to the controller's documentation.
1 Press the UP or DOWN button so many times until DMX Address is indicated on the display. Confirm
with the ENTER button.
2 Now the display calls up the menu item for the DMX starting address: 001.
3 Use the buttons UP and DOWN to set the address. Confirm with the ENTER button.
4 In order to choose the desired DMX channel mode, press the UP or DOWN button so many times until
DMX Channel is indicated on the display. Confirm with the ENTER button.
5 The display indicates 10 CH (10 DMX channels) or 15 CH (15 DMX channels). Use the buttons UP and
DOWN to select the desired DMX channel mode. Confirm with the ENTER button
6 The DMX Mode control indicator beside the OLED display will light up when DMX signals are being
received.
Note: Please make sure that you do not have any overlapping channels in order to control each device
correctly and independently from any other fixture on the DMX chain. If several devices are addressed
similarly, they will work synchronically.

Functions in DMX mode

10 15
Value
CH CH
1 1
0
2
0
2 3
0
4
0
5
0
3 6
0
0
4 7
5
251
Horizontal movement (PAN)
Push slider up in order to move the head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other
255
(0-255, 128-center). The head can be stopped at any position you
wish.
PAN-movement with 16-bit resolution
255 Fine indexing
Vertical movement (Tilt)
Push slider up in order to move the mirror vertically (TILT).
Gradual mirror adjustment from one end of the slider to the other
255
(0-255, 128-center). The mirror can be stopped at any position you
wish.
TILT-movement with 16-bit resolution
255 Fine indexing
PAN/TILT speed
255 Increasing speed
Dimmer intensity
Gradual adjustment of the dimmer intensity from 0 to 100 %
255
Shutter, Strobe
4 No function
250 Strobe-effect with increasing speed
255 No function
Feature
