DESCRIPTION OF THE DEVICE

1
2
3
4
5
6
7
8
16
17
18
9 10 11 12 13
14
15
19
20
21
(1) Mirror
(2) Objective-lens
(3) Fixation screw
(4) DMX Mode control indicator
(5) Power control indicator
(6) Microphone
(7) Ventilation slots
(8) Rubber foot
(9) Menu button
(10) Up button
(11) Down button
(12) Enter button
(13) OLED display
(14) Hole for the mounting coupler
(15) Mounting bracket
(16) Safety eyelet
(17) DMX input
(18) Power input
(19) Fuseholder
(20) DMX output
(21) Power output
