TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
IP classification:
Power connection:
Power output:
Fuse:
LED:
Color temperature:
Beam angle:
Max. TILT movement:
Max. PAN movement:
Flash rate:
Equipment:
Color generation:
Gobos:
DMX channels:
DMX input:
DMX output:
Cooling fan:
Control:
Housing color:
Width:
Height:
Depth:
Weight:
251 mm
31/32
100-240 V AC, 50/60 Hz
110 W
IP20
Mains input P-Con (blue), mounting version Power
supply cord with safety plug (provided)
P-Con (gray), mounting version
T time-lag, 2 A Fuse replaceable
1 x COB (chip-on-board) 100 W
8000K
20°
Exact positioning (16 bit resolution) 50°
Exact positioning (16 bit resolution) 160°
1 - 25 Hz
Focus motor-driven; Color wheel; Gobo wheel with
rotating gobos; Prism 3-fold
Color wheel 8 dichroic filters plus open
Gobo wheel with 7 gobos and open
Shake effect
10; 15
3-pin XLR (M) mounting version
3-pin XLR (F) mounting version
Yes
Stand-alone
DMX
Master/slave function
Sound to light via Microphone
Black
25.1 cm
37.7 cm
14.1 cm
5.5 kg
141 mm
