OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board or in DMX-controlled mode via any commercial DMX controller.
After you connected the effect to the mains, the EUROLITE LED TSL-1000 Scan starts running. During the
Reset, the motors are trimmed and the device is ready for use afterwards.

Menu structure

Browse through the main menu by pressing Enter. Press Enter in order to select the desired menu item.
You can change the selection by pressing Up or Down. Press Enter in order to confirm. You can leave every
mode by pressing Menu. The functions provided are described in the following sections.
The display shuts off after 10 seconds of inactivity. By pressing any button it lights up again.
Default shown in grey.
Main meun
DMX Address 001~ 512
DMX Channel DMX 10 CH / DMX 15 CH
DMX
Auto
Running Mode
Sound
Slave
Programs Program 1 ~ Program 8
Pan Rev
Tilt Rev
Display Rev
Sensitivity
Settings
DMX Fail
Calibration
Factory Reset
Reset Motor
Software V X.XX
System Info Mode XXX
Address 001
Sub menu
DMX address setting
DMX channel mode
DMX mode
Auto mode
Music control
Master/Slave setting
Auto programs
YES
PAN reverse
NO
YES
TILT reverse
NO
YES
Display reverse
NO
000-100 Microphone sensitivity
OFF
Action if no DMX
HOLD
Service only
YES
Reset to factory settings
NO
Motor reset
Shows the current software version
Shows the operating mode
Shows the DMX starting address
25/32
Function
