DMX Address
With this function, you can adjust the desired DMX address via the Control Board.
DMX Channel
With this function, you can select the desired DMX channel mode.
Running Mode
With this function, you can select the desired operating mode:
DMX
Auto
Sound
Slave
Programs
With this function, you can select the desired internal program (1 ~ 8):
Settings
With this function, you can select several operating parameters:
Pan Rev = With this function, you can reverse the PAN-movement.
Tilt Rev = With this function, you can reverse the TILT-movement.
Display Rev = With this function, you can flip the display by 180° for a better view when the fixture is hung
from a truss or a ceiling.
Sensitivity = With this function, you can select the desired microphone sensitivity between 0 % and 100 %.
DMX Fail = With the function you can "keep" (HOLD) or "clear" (OFF) the DMX value if there is no DMX-
signal.
Calibration = Service only.
Factory Reset = With this function you can reset the parameters to factory default.
Reset Motor = With this function you can reset the motors via the Control Board.
System Info
With this function, you can display several operating parameters
