Control Board

The Control Board offers several features: you can e. g. simply set the starting address.
Browse through the menu by pressing Menu. You can change the selection by pressing Up or Down. You
can leave every mode by pressing the Menu-button. The functions provided are described in the following
sections.
After you connected the effect to the mains, the display indicates "rES" followed by:
Main menu
d001
SLAE
M--A
P--F positiv
P--F
P--b reverse
T--F positiv
T--F
T--b reverse
C-on

DMX-controlled operation

You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.

Addressing

The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the LED TSL-600 Scan COB will respond to the controller.
If you set, for example, the address to channel 8, the device will use the channel 8 to 14 for control.
Please, be sure that you don't have any overlapping channels in order to control each LED TSL-600 Scan
COB correctly and independently from any other fixture on the DMX data link.
If two, three or more LED TSL-600 Scan COB are addressed similarly, they will work similarly.
For address setting, press the Menu button until the display shows „d001" and set the desired address via
the Up/Down-buttons.
Controlling:
After having addressed all LED TSL-600 Scan COB, you may now start operating these via your lighting
controller.
Note:
It's necessary to insert the XLR termination plug (with 120 Ohm) in the last lighting in the link in order to
ensure proper transmission on the DMX data link.
Display Function
With this function, you can adjust the desired DMX-address via
001-512
the Control Board.
With this function, you can define the device as slave.
Automatic program mode when there is no DMX signal and
M--A
that the device is defined as master.
Sound-controlled mode when there is no DMX signal and that
M--S
the device is defined as master.
Neutral position (is only meant for service-purposes) and that
M--B
the device is defined as master.
With this function you can reverse the Pan-movement.
With this function you can reverse the Tilt-movement.
Display close time
C-of With this function you can shut off the LED display after 15
seconds.
