Noise Reduction: Compared to other forming methods, the EO2-FORM process results in a smooth
inner contour of the tube that does not allow the accumulation of air, dirt or other sources of trouble.
Less pressure drop, heat and noise is created.
Re-usability: EO2-FORM connections can be disassembled and reassembled many times.
There is no wear or widening of the vulnerable fitting inner cone.
Approved: Both, EO2 high pressure tube fittings and the EO2-FORM process are tested and
approved by independent organisations such as Germanischer Lloyd and Det Norske Veritas (DNV).
Small bending radii: The compact clamping device and special dies are suitable for forming short
tube ends.
Clean: The EO2-FORM process is environmentally clean and safe. As no heat is used, hazards from
chemicals, fumes or heat do not occur.

The EO2-FORM connection:

4.3
Screw nut
Fitting body
Tube
EO2 – Seal (DOZ )
