Storage
RAID
Connector
12
• 6 x SATA3 6.0 Gb/s Connectors*
• 2 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061
* M2_2, SATA3_0 and SATA3_1 share lanes. If either one of
them is in use, the others will be disabled.
* M2_3, SATA3_4 and SATA3_5 share lanes. If either one of
them is in use, the others will be disabled.
• 1 x Hyper M.2 Socket (M2_1), supports M Key type
2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s)
th
(with 11 Gen Intel® Core™ Processors) or Gen3x4 (32 Gb/s)
th
(with 10 Gen Intel® Core™ Processors)**
• 1 x Ultra M.2 Socket (M2_2), supports M Key type
2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI
Express module up to Gen3 x4 (32 Gb/s)**
• 1 x Ultra M.2 Socket (M2_3), supports M Key type
2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI
Express module up to Gen3 x4 (32 Gb/s)**
** Supports Intel® Optane
** M2_1 supports Intel® Optane
TM
Gen Intel® Core Processors
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
• Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
• Supports RAID 0 and RAID 1 for M.2 NVMe storage de-
vices*
* RAID function for PCIe mode SSD in M2_1 is only available
with Intel® SSD installed (with 11
• 1 x Power LED and Speaker Header
• 2 x RGB LED Headers
* Support in total up to 12V/3A, 36W LED Strip
• 2 x Addressable LED Headers
* Support in total up to 5V/3A, 15W LED Strip
• 1 x CPU Fan Connector (4-pin)
* The CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
TM
Technology
TM
Technology only with 10th
th
Gen Intel® Core™ Processors).
