1 x Gigabit LAN 10/100/1000 Mb/s (Intel® I219V)
• Supports Wake-On-LAN
• Supports Lightning/ESD Protection
• Supports Energy Efficient Ethernet 802.3az
• Supports PXE
Wireless • Intel® 802.11ax Wi-Fi 6E Module
LAN • Supports IEEE 802.11a/b/g/n/ax
• Supports Dual-Band 2x2 160MHz with extended 6GHz
band* support
* Wi-Fi 6E (6GHz band) is not currently enabled by default
due to the different regulation status of each country. It will be
activated (for supported countries) through Windows Update
and software update once available. The update is expected to be
in the middle of 2021.
• 2 antennas to support 2 (Transmit) x 2 (Receive) diversity
technology
• Supports Bluetooth 5.2 + High speed class II
• Supports MU-MIMO
• 2 x Antenna Ports
Rear Panel
I/O • 1 x PS/2 Keyboard Port
• 1 x PS/2 Mouse Port
• 1 x Optical SPDIF Out Port
• 3 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (ReDriver)
(Supports ESD Protection)
• 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver) (Supports
ESD Protection)
• 4 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection)
* USB3_1 is from Intel® Z590; USB3_234 are from ASMedia
ASM1074 hub.
* Ultra USB Power is supported on USB3_234 port.
* ACPI wake-up function is not supported on USB3_234 port.
• 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED
LED)
• 1 x BIOS Flashback Button
• 1 x BIOS Selection Switch
• HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone (Gold Audio Jacks with LED)
* This motherboard does not support integrated graphics.
