1. Introduction

Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschine GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
We hope your new tool brings you much enjoyment
and success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified,
We recommend:
Read through the complete text in the operating in-
structions before installing and commissioning the
device. The operating instructions are intended to
help the user to become familiar with the machine
and take advantage of its application possibilities in
accordance with the recommendations. The operat-
ing instructions contain important information on how
to operate the machine safely, professionally and
economically, how to avoid danger, costly repairs, re-
duce downtimes and how to increase reliability and
service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regu-
lations that apply for the operation of the machine in
your country. Keep the operating instructions pack-
age with the machine at all times and store it in a
plastic cover to protect it from dirt and moisture.
Read the instruction manual each time before op-
erating the machine and carefully follow its informa-
tion. The machine can only be operated by persons
who were instructed concerning the operation of the
machine and who are informed about the associat-
ed dangers. The minimum age requirement must be
complied with.
In addition to the safety instructions contained in this
operating manual and the specific regulations of your
country, the technical rules generally accepted for
the operation of machines of the same type must
be observed.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58

2. Device description

1. Cutting lever with extension bar
2. Hinged arm
3. Base frame
4. Setting spindle
5. Upper blade
6. Lower blade
7. Support foot
8. Support
9. Transport wheel
10. Transport hook

3. Scope of delivery

A. Block splitter with upper and lower blades
B. Extension bar for cutting lever
C. Support foot
D. Disconnect lever
E. Enclosed accessories bag with:
- M8 x 20 mm cylindrical screw with two washers
and a self-locking nut (4x)
- M12 x 60 mm hexagonal bolt with two washers
and a self-locking nut (2x)
- 10 x 38 mm pin
- Pivoted lever
- Transport hook
F. Operating manual
G. Enclosed accessories bag with:
- Open-ended spanner, size 13 / 16
- Open-ended spanner, size 16 / 18
- Open-ended spanner, size 17 / 19
- 4 mm hexagon spanner
- 5 mm hexagon spanner
- 6 mm hexagon spanner

4. Intended use

The block splitter is intended only for private use in
the home and garden.
The block splitter is intended exclusively for cutting
concrete blocks, tiling and kerbstones.
Any other use is deemed to be a case of misuse.
The user / operator and not the manufacturer will be
liable for any damage or injuries of any kind caused
as a result of this.
To use the equipment properly you must also ob-
serve the safety information, the assembly instruc-
tions and the operating instructions to be found in
this manual.
All persons who use and service the equipment have
to be acquainted with this manual and must be in-
formed about the equipment's potential hazards.
It is also imperative to observe the accident preven-
tion regulations in force in your area. The same ap-
plies for the general rules of health and safety at
work.
GB | 17
